Bag Closing Machine Industrial Rice Bag Closer Sewing Machine Gk35
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xPackaging Type | Cartons | Packaging Material | Plastic, Wood |
---|---|---|---|
Driven Type | Electric | Warranty | Unavailable |
Key Selling Points | Energy Saving | Machinery Test Report | Not Available |
Core Components | Other | Type | Wrapping Machine |
High Light | bag closer sewing machine gk35,gk35 bag sewing machine,gk35-2c bag sewing machine |
Bag closing machine industrial rice bag closer sewing machine gk35
Product Description
GK35-2C Bag Closing Machine: Single needle machine for closing of all kinds of filled bags made of multi-wall paper, PP/PE woven cloth, jute, cotton bags etc. Equipped with mechanically operated continuously running thread chain cutting knives, the operator has to guide the thread chain between these knives for cutting the thread chain at the end of the seam.
GK35-2CF is a left hand bag closer based on GK35-2C.
GK35-2CS is equipped with synchronous feeding device. it is designed for closing bags made of extra heavy duty materials such as multi-wall paper, PP/PE woven cloth. It is suitable for film coated bags with “M” edge and bags which is fold over before sewing.
1. Start-stop: actuated by foot switch of column
2. Thread chain cutter: by continuously driven nibbler knives
3. Standard needle: 80800x 250#
4. Stitch type: Double threads chain stitch 401 (Single thread chain stitch is available)
5. Stitch length: adjustable from 6.5-11 mm, standard setting 8 mm
6. Speed: up to 2000 RPM, depending on sewing material and operation
7. Net weight: 33Kg
8. Package: Carton,500*500*330mm
9. As our standard bag closers do not include any electric components, they can be installed in ex-proof locations.
Specification
No | Item | Data | No | Item | Data |
1 | Speed (max.) | 2000r.p.m. | 7 | Needle type | 80800×250# |
2 | Sewing thickness | 8mm | 8 | Pulley diameter | φ 114mm |
3 | Stitch length | 6.5-11mm | 9 | Thread chain cutter | by continuously driven nibbler knives |
4 | Stitch type | double threads chain 401 | 10 | Motor power | 370w |
5 | Thread | cotton, polyester | 11 | Net weight | 32KG |
6 | Presser foot lift | 11-16mm | 12 | Package: | 50cm * 50cm * 35cm |
Features
1. Start-stop: actuated by foot switch of column
2. Thread chain cutter: by continuously driven nibbler knives
3. Standard needle: 80800x 250#
4. Stitch type: Double threads chain stitch 401 (Single thread chain stitch is available)
5. Stitch length: adjustable from 6.5-11 mm, standard setting 8 mm
6. Speed: up to 2000 RPM, depending on sewing material and operation
7. Net weight: 33 Kg
8. Package: Carton,500*500*330 mm
9. As our standard bag closer do not include any electric components, they can be installed in ex-proof locations.
