Electric Water Well Drilling Machine 75mm 100mm 200mm 150mm Borehole Rig

Place of Origin China
Brand Name Infectious
Certification CE
Model Number WDM-01
Minimum Order Quantity 1 sets
Price $790.00-$850.00 Sets
Delivery Time 7-15 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 20000 Sets Week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Weight 400 KG Core Components Motor, Pressure Vessel, Pump, Engine
Drilling Diameter 75mm, 100mm, 200mm, 150mm Drilling Depth Max.100m
Power Type Electric Voltage 380v/220V
High Light

electric water well drilling machine 75mm


electric hydraulic water well drilling machine


75mm hydraulic water well drilling machine

Leave a Message
Product Description

100m Deep Portable Hydraulic Water Well Rotary Drilling Rig /borehole Water Well Drilling Machine With Electric Start


Product Description

100m Deep Portable Hydraulic Water Well Rotary Drilling Rig /borehole Water Well Drilling Machine With Electric Start

Hydraulic lift electric drilling rig is a new mechanized drilling rig with high efficiency, light weight, economy and
practicability produced by our factory. Its advantages are: large torque, small volume, portable, high efficiency, easy operation,low noise and adaptability to various environmental topography. The machine is easy to use, simple to operate, fast to form holes.It can be operated by a single person at about 10 meters per hour. It can dump the drill pipe mechanically. Taking a well drilled at 100 meters as an example, the average time of drill pipe disassembly takes about 10 minutes. After completion of drilling operation, the machine can be moved by a single person.

Daily maintenance:
1. The motor part of the drill should be handled with care to avoid rain and splash.
2. Motor wire connector shall not touch to connect with electricity.
3, often check whether the wire rope replacement.
Check the connection of each part of the oil pipe, whether there is oil leakage and whether the oil level is normal.
5, before and after the use of the drill pipe wire head with oil lubrication placed in the rain shelter, so as to avoid rust.
6. The motor shall not be overloaded for a long time.
7. Check the circuit and transformer insurance when the motor does not work.
8. It is strictly prohibited to continuous pressure the cylinder when it rises or falls to the end position of the stroke.
9. During the period when the drilling machine is not in use, the water in the water injector and the water pump shall be drained in time, and the connection with the drilling machine shall be disconnected and stored separately.


No Parameter Unit BF-hydraulic lifting electric drilling rig
1 Power Voltage V 220/380(Positive and Reversible)
2 Motor Power Kw Main Motor 3kw/5KW/7.5KW, Oil Pump 3KW
3 Borehole diameter mm 32-220
4 Drill pipe diameter   1 inch, 1.2 inch, 1.5 inch various specifications and lengths can be selected
5 Bit Specification   Multi-bore Alloy and Diamond Bit Selection
6 Drilling depth M 100
7 Weight Kg 200
8 Suitable for soil   mud layer, quicksand layer, small amount of rock layer, pebble, etc.


Electric Water Well Drilling Machine 75mm 100mm 200mm 150mm Borehole Rig 0Electric Water Well Drilling Machine 75mm 100mm 200mm 150mm Borehole Rig 1Electric Water Well Drilling Machine 75mm 100mm 200mm 150mm Borehole Rig 2
Company introduction
Zhejiang Xingyi Technology Co., Ltd is a professional machinery equipment manufacturer located in Henan Province, China. The company specializes in the production, processing and sales of food machinery, agricultural machinery and other machinery. We mainly cover the production scope: snack food processing machinery, candy processing machinery, fruit and vegetable processing machinery, printers, packaging machinery, water well drilling machine, various peeling machines.
The company covers an area of 10,000 square meters, with fixed assets of 50 million yuan. There are more than 100 employees, more than 30 technical personnel, and more than 100 sets of various production equipment. Equipment includes: large press machine, digital lathe, digital wire electrode cutting equipment, all kinds of processing machinery and equipment. The company has national patents and proprietary technology, with independent research and development capabilities.
After-sales Service
1 24 hour communication service
2 Fast logistics will provide you a smooth delivery service
3 One-year warranty and lifetime technical support
4 New design or product recommendation
5 Attend international Fair to negotiate with customer face to face
6 offer official invitation if you come to China
7 Reception service,help you to book good hotel
Q1 :What's your company after-sales service?
A1: We will check three times before shipment to ensure that the machine itself has no problems.Offering the best quality machine&the best service to our customers is the mission of our enterprise.
Q2 :Any warranty ?
A2:One year warranty. Frankly speaking, the quality of our machines is very stable. The machine will be checked three times before leaving the factory to ensure that you can receive the machine in the best condition. If you have any questions, we can make a video call at any time.
Q3: How to transport without customs clearance experience ?
A3:We have reliable forwarder agent which can ship items to you by sea/air/Express to your home. We will help you choose the most suitable shipping service.
Q4: Differences from other brands in China ?
A4:We are not only selling machines, we pay more attention to after-sales service. We have always believed that the customer's reputation is the best advertisement.
We hope to really help our customers use machines and bring growth to their business. You can view our customers' feedback, facts speak louder than words.
Q5 :Can I print my logo on the machine ?
A5: Yes, sure. We can provide professional customized logo services for customers.
Q6 :How does your factory do regarding quality control?
A6: Quality is priority. We always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
