China Automatic Food Making Machine manufacturer

Restaurant 500L Automatic Hydraulic Mixer Sugar Melting Machine

Product Details:
Place of Origin: China
Brand Name: Fude
Certification: CE,UL,ISO9001,FDA
Model Number: FD-J-100
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 1000usd 10000usd
Packaging Details: wooden case packages
Delivery Time: 5
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000

Detail Information

Applicable: Food & Beverage Factory, Restaurant, Home Use Condition: New
Voltage: 220V/380V Weight: 300kg
Warranty: 2years Material: 304SS
Heating Power: Electric,gas,steam Motor Power: 2.2kw+1.5kw
Discharge Way: Automatic Hydraulic Dimension: 1900*1500*1600 Mm
Volume: 100l To 1000L Capacity: 60kg -200kg/hour
High Light:

500L Sugar Melting Machine


500L Jacketed Kettle Cooker


Hydraulic Sugar Melting Machine

Product Description

Automatic cooking machine planetary mixer

Delicious Sugar melting and coated making machine with mixer


Product introduction:


1. The sandwich pot is also known as a steam pot, a cooking pot, and a sandwich steam pot.

2. It usually consists of a pot body and legs. The pot body is a two-layer structure composed of a spherical body inside and outside.

3. The sandwich pot is divided into structure according to the structure: tiltable sandwich pot, vertical sandwich pot, horizontal horizontal sandwich pot.

4. The sandwich pot is divided into heating method: electric heating sandwich pot, steam heating sandwich pot, gas heating sandwich pot.

5. The sandwich pot is divided according to the process requirements: no stirring sandwich pot, planetary stirring sandwich pot, scraping bottom stirring sandwich pot.


Main Technical Parameters of 500l big equipment pasta sauce cooking machine for instant noodle chocolate melting bowl 50l pot still sugar melter :

Model Volume Electric Heating Power Mortar Power Heating Area Pot Inner Diameter Weight Dimension(cm)
JC-50 50L 15kw 0.75kw 0.53m2 500mm 75kg 80*80*120
JC-100 100L 15kw 1.1kw 0.87m2 700mm 90kg 90*90*120
JC-200 200L 15kw 1.1kw 1.23m2 800mm 120kg 100*100*120
JC-500 500L 27kw 2.2kw 2.21m2 1100mm 235kg 140*140*150
JC-600 600L 30kw 2.2kw 2.43m2 1200mm 250kg 150*150*150
JC-800 800L 30kw 3kw 2.87m2 1300mm 305kg 170*170*150
JC-1000 1000L 30kw 3kw 3.09m2 1400mm 360kg 190*190*170


Main Features


● simple operation automatic,intelligent and one button, safe operation and stable performance
● uniform stirring no any stirring blind spot in the pot
● energy saving and environmental protection without waste residue and noise pollution
● rapid heating achieve the target temperature with short time
● safe use inductive heating and no danger of fire
● use hydraulic thrust to tilting pot body, make the material is easy to in and out and save manpower.

● Food grade stainless steel is safety and healthy




Restaurant 500L Automatic Hydraulic Mixer Sugar Melting Machine 0


Restaurant 500L Automatic Hydraulic Mixer Sugar Melting Machine 1


Restaurant 500L Automatic Hydraulic Mixer Sugar Melting Machine 2
